Sharples AS16V vertical centrifuge with a maximum G force of 8,435, bowl rpm speed of 12,000 and a bowl capacity 5.1 liter. Applies centrifugal force to a liquid when fluids enter rotating bowl. Enjoy the videos and music you love, upload original content, and share it all with friends, family, and the world on YouTube.

Continuous Solid-Liquid Separation

Solids are continuously separated from the liquid phase by the application of centrifugal force ranging up to 3000 times the force of gravity, efficiently and economically. A characteristic feature of the Pennwalt Super-D-Canter Centrifuge is the cylindro-conical bowl containing within a helical/quasi-axial screw conveyor of matching profile that rotates in the same direction but at a slightly slower speed with respect to the bowl.

Extremely flexible Separations Tool

  • Handles slurries with a wide range of solid particle sizes from 5.0 mm to a few microns
  • Handles slurries with insoluble solids content from as low as 0.5%w/v to as high as 55%w/v.

Wide ranging, process specific applications of Pennwalt Super-D-Canter Centrifuge encompass:

Sharples Centrifuge Manual
  • Clarification of liquids.
  • Dewatering or de-liquoring of insoluble suspended solids.
  • Thickening or concentration of insoluble suspended solids.
  • Classification of insoluble solids suspended in liquid.

For a detailed list of applications where the Pennwalt Super-D-Canter Centrifuge has been successfully used click here

Economical Operation

Pennwalt Super-D-Canter Centrifuge has polymiser features, wherein the feed zone & conveyor flights are modified to reduce the floc breakage and minimise conveyor turbulence in the pool. These features result in considerably reduced dose of polymeric flocculants. In addition there is a substantial economy of space, power and labour required in the operation of the Pennwalt Super-D-Canter Centrifuge in comparison with alternative solid-liquid separations equipment.

Stainless Steel Construction designed to resist corrosion

Carbon Steel corrodes, leading to unbalance, high maintenance costs, long downtimes. Therefore the principle elements and stressed rotating components of Pennwalt Super-D-Canter Centrifuge are machined from quality centrifugally cast Stainless Steel.

Sharples

Designed to resist abrasion

Sintered Tungsten Carbide Tiles positioned on the flights of the Pennwalt Super-D-Canter Centrifuge scroll (conveyor) outlast conventional hard surfacing systems many times over in any environment.

BD Feature

This makes slimy and gelatinous sludges SCROLLABLE. The BD feature allows the Super-D-Canter to operate at Ultra-Deep pond settings that compact the solids and creates hydrodynamic buoyancy that assists the scrolling and the discharge of slimy sludge. The insoluble solid contents are typically 1/2% - 2% in the feed slurry which are thickened to 6%-12% and discharged in the slimy cake.
3-Phase:
This is a Pennwalt Super-D-Canter Centrifuge which is designed to give three separate product phases such as water, Oil, and Cake Solids. Applications encompass Olive Oil, Fish Oil, Fish Blood-Water, Slop Oietc.
Often, one or both liquid phases need to be further polished on the high-G Tubular Bowl Super centrifuge.

Sterile Features

For Pharmaceutical, Biotechnology and Food Industries, the Pennwalt Super-D-Canter Centrifuge can be provided with Sterilisation-in-place (SIP) and Clean-in-Place (CIP) features.

Safety Features

  • All electric drives are provided with enclosures of Ingress Protection (IP) ratings selected for safe operation as per process requirements.
  • The Pennwalt Super-D-Canter centrifuges are designed and featured for operational safety with Inert Gas (N2) purging to be provided by the end use customer, when operated with feed slurry containing a flammable and/or explosive solids or liquid phase.

Performance :

Four crucial factors govern the separational performance of Pennwalt Super-D-Canter centrifuges.

  • Centrifugal force required to sediment the solids.
  • Appropriate setting of the pool depth to achieve the required centrate liquid clarity.
  • Control of differential speed between the bowl and scroll, to convey the solids and obtain appropriately low cake moistures.
  • Hydrodynamic design of the conveyor to minimise turbulence.

In specifying a Super-D-Canter centrifuge, for a particular application, Pennwalt also considers other design features such as:

Sharples P3400 Decanter Centrifuge Specs

  • The pitch of the conveyor flights.
  • Number of Leads of the Conveyor.
  • Special Rinse or Floc Feature.
  • Feed zone design.
  • Beach angle.
  • Beach Internal Surface Profile.
  • Bowl Internal Surface Profile.
  • Torque Sensing and Over-load Protection.
  • Back-Drive or Eddy Current Brake for control of Differential Speed.
  • Casing Enclosure design.
  • Abrasion Protection with Tungsten Carbide Tiles or Stellite Hard Surfacing of the Conveyor.
  • Material of construction.
  • Sedimentation enhancing features and choice of polyelectrolyte flocculants.
  • Safety Featured casing and guards.

The correct combination of such features ensures the desired separational performance with operational safety for a given application at minimum cost. Operation at High 'G' force is an inherent design feature of the Pennwalt Super-D-Canter and provides flexibility to the user. The centrifuge can be operated at an optimum speed to suit the particular application. The Pennwalt Super-D-Canter can be operated at low, intermediate or high speed without the constraints of mechanical design, which can be optimised and tailored to suit each application.

ADVANTAGES OF PENNWALT SUPER-D-CANTER

  • Reduces Total disposal volume substantially
  • Saves space due to small foot print
  • Saves power in comparison with filtration equipment
  • Reduces handling costs
  • Produces Truckable cake solids discharge
  • Totally enclosed casing for odour minimisation and solvent loss minimisation
  • Automated Decanter Operation
  • Continuous Operation
  • Tailored to application specific requirements

Construction

Alfa Laval & Sharples Repair

REPAIR YOUR ALFA LAVAL CENTRIFUGE TODAY

Take advantage of our expertise and call on our highly qualified service engineers to help you rebuild your Alfa Laval.

Sharples Repair / Alfa Laval Repair

Alfa Laval is the pioneer of separation technology. From high speed disc to large volume decanters, we got you covered! Text or Call us today.

Centrifuge World has a range of service offerings to enhance the performance of your equipment. Depending on the nature of the service. These services are performed at one of our specialized Centrifuge World Service centers located in Houston, Texas and Chicago Illinois.

Centrifuge World offers comprehensive reconditioning and repair services for decanter centrifuges, which are performed at Centrifuge World Service centres. These services ensure equipment continues to deliver high efficiency and optimal performance.

To keep your equipment running in top operating condition, maintenance is essential. To take advantage of our expertise, you can call on our highly qualified service engineers to help troubleshoot maintenance issues onsite or advise you at your facility. 281-565-8777

Repairing decanter and disc stack separators

When rotating equipment requires repair, Centrifuge World provide the following services for our decanters and disc stack separators:

Sharples P5000 Centrifuge Manual

Standard maintenance, when service in the field is not convenient
Welding of areas damaged due to mechanical, chemical or erosion attacks
Refitting of wear parts, such as o-rings and gaskets
Replacing worn out or damaged items
Executing upgrades
Balancing static and/or dynamic equipment based on needs and available equipment
Conducting a test run, depending on the equipment

Sharples Centrifuge Manual Free

Moving Forward!

Sharples Centrifuge Manual

Whether reconditioning or repairing equipment, you receive comprehensive report from our qualified service engineers. The report details service findings as well as recommendations on how to adjust equipment to suit current process or operating conditions, if required. You also get an overview of the equipment parts that most likely will require replacement at the next service interval. This gives you peace of mind and ensures more uptime and greater availability of your equipment.
